Rise 3 Standing Wheelchair
A five-function electric chair with vertical lift, standing, lie-flat recline and seat tilt, lifting to a 1 m hover height.
5-in-1 electric standing wheelchair (Model DW-EW307-5): vertical lift to 1 m, standing, lie-flat recline and seat tilt, with a self-locking safety system.
Architectural Design & Therapeutic Intent
The Rise 3 (Catalog Model DW-EW307-5) is a 5-in-1 multi-functional electric chair: fully powered vertical lift, standing, lying flat (recline) and buttock lift / tilt. The seat lifts to a hovering height of 95 to 100 cm from the ground.
A self-locking motor push-rod system helps prevent unintended drops or shifts, and rear anti-roll wheels add stability. Quick-release armrests and foot pedals, an adjustable backrest angle and an optional electric leg-lift package make it modular.
Two 24 V 350 W motors run from a 24 V 40 Ah lead-acid battery to a speed of 0–8 km/h and a range of 25 km, controlled by a single-handed 360° joystick.
Powered Lift, Stand and Recline
Electric actuators raise and recline the seat, locked by a self-locking push-rod system, while two 350 W motors drive the chair.
- 1Powered vertical lift to 95–100 cm.
- 2Standing, lie-flat recline and seat tilt functions.
- 3Self-locking motor push-rod system and rear anti-roll wheels.
- 4Electronic brake + electromagnetic brake.
Engineered Capabilities & Advanced Controls
5-in-1 Articulation
Vertical lift, standing, lying flat and buttock lift / tilt.
1 m Hover Height
Seat lifts to 95–100 cm from the ground.
Safety Lock
Self-locking push-rod system with rear anti-roll wheels.
Modular Design
Quick-release armrests and foot pedals, adjustable backrest, optional electric leg-lift.
Single-Handed Joystick
360° universal joystick controller.
Evidence-Based Biological Benefits
Five Functions
One chair covers lift, stand, recline and tilt.
Big Battery
24 V 40 Ah for a 25 km range.
Full Technical Specifications
Performance Specifications6 Parameters Calibrated
Turnkey Delivery & Included Components
Recommended Session Protocols
Calibrated to maximize therapeutic outcome without triggering biological exhaustion.
Cumulative regenerative benefits compound with consistent weekly integration.
- •A mobility product should be matched to the user. Have a clinician or mobility specialist confirm suitability and seating, and never exceed the stated weight capacity.
Step-by-Step Operator & User Procedure
Pre-Session Checklist
- Charge the battery fully before first use and check the charge level before each trip.
- Check tyres, brakes and the folding lock, and adjust the seat to the user.
- Use lift and standing functions only as instructed, with the chair on level ground.
Session Execution Steps
Inspect the chair, switch it on and check the battery indicator.
Use the controller at a speed suited to the surroundings and stay within the weight capacity.
Switch off, fold or park on level ground, and recharge after use.
Turnkey Facility Integration
Homecare & Individuals
Personal mobility for everyday life at home and outdoors.
Senior Living
A dependable chair for residents and care teams.
Hospitals & Clinics
A reliable chair for patient movement and rehabilitation settings.
